| الاسم التجاري: | Innolux |
| رقم الطراز: | SG2701B08-1 |
| الـ MOQ: | 10 قطعة |
| السعر: | negotiable |
| شروط الدفع: | / تي تي، ث، ويسترن يونيون، موني جرام |
| القدرة على العرض: | 3000pcs في الأسبوع |
27-inch CSOT LVDS desktop monitor module featuring 1920×1080 resolution, 81ppi pixel density, and 250 cd/m² brightness. This SG2701B08-1 Ver.7.1 model is a 27.0" diagonal a-Si TFT-LCD display panel from China Star Optoelectronics Technology Co., Ltd (CSOT).
| Brand | CSOT |
| Model Number | SG2701B08-1 Ver.7.1 |
| Panel Type | a-Si TFT-LCD, CELL, FOB |
| Resolution | 1920(RGB)×1080 (FHD), 81PPI |
| Active Area | 597.888 × 336.312 mm |
| Outline Dimensions | 608.888 × 347.312 × 1.3 mm (H×V×D) |
| Refresh Rate | 144Hz |
| Contrast Ratio | 1500:1 (Typical) |
| Response Time | 14ms (Typical, G to G) |
| Viewing Angle | 89/89/89/89 (Typical, CR≥10) |
| Color Depth | 16.7M colors, 99% sRGB |
| Signal Type | LVDS (2 ch, 8-bit), 30 pins Connector |
| Operating Voltage | 5.0V (Typical) |
| Work Mode | IPS, Normally Black, Transmissive |
| Surface Treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Glass Thickness | 0.50+0.50 mm |
| Transmissivity | 6.4% (Typical, with Polarizer) |
| Driver IC | Built-in COF 6 source chips |
| Weight | 680g (Typical) |
| Backlight | No backlight included |
| Touchscreen | Without touch screen |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -20°C to 60°C |
